6MR400SEAL PRO | 6.5" SEALED BASKET MIDRANGE LOUDSPEAKER

$49.91 USD
$49.91 USD $62.39 USD
Sale Sold out

About the Product

The 6MR400SEAL PRO offers very smooth midrange response to the upper midrange up to 9,000 Hz. Designed to provide definition and high output on midrange frequencies, perfect for use in any high output 3-way system.



Now you can pair this 6.5″ speaker with any 10″ or 12″ speaker from our PRO Series, to build the ultimate custom Chuchero® or PRO Audio systems.

6MR400SEAL PRO
  • A sealed back basket simplifies cabinet manufacture, eliminating the need for a separate enclosure for other speakers.
  • Capable of handling 400 Watt RMS this midrange has enough output capability to keep up with the most powerful drivers, suitable for use in 3-way cabinet systems ( Midbass + Seal Basket + High Frequency Driver or Tweeter).
  • Optimized to deliver detailed reproduction of mid-range frequencies from 300Hz to 9,000Hz. A powerful output peak at 400hz reaches 100dB of sensitivity at 1w/1m.

6MR400SEAL PRO

A light paper cone is mated to a 1.5″ voice coil for great power handling of 400 watts. A durable spider suspension, woven cloth surround, and closed back pressed steel basket are combined for durability over many hours of use.

Cabinet builders gravitate towards this driver for use in their systems when looking for a powerful sealed basket midrange, to keep up with high sensitivity low frequency speakers.


8MR500SEAL PRO

Using a closed basket design in a speaker like the 6MR400SEAL PRO offers several advantages. Firstly, it prevents interference from a woofer or midbass in a shared cabinet design, resulting in a cleaner and more accurate midrange response.

Additionally, the closed basket design contributes to a smooth punch of midbass and midrange, enhancing the overall audio performance of the speaker.


PRV 6.5″ Sealed Basket Midrange 6MR400SEAL PRO Audio Speaker / 8 Ohm – High Performance



GENERAL SPECIFICATIONS

Nominal Diameter 6″ (152 mm)
Nominal impedance 8 Ohm
Nominal Power Handling 200 Watts
Continuous Program Power (RMS) 400 Watts
Max Peak Power 800 Watts
Sensitivity 2.83V at 1m 96 dB
Recommended Hi Pass Crossover** **For Full Power Handling 400 Hz** **12db Per Octave Crossover
Frequency Response at -10DB 400 – 9,000 Hz
Voice Coil Diameter 1.5″ (38 mm)
Voice Coil Wire Copper
Voice Coil Winding Depth 10.0 mm
Former Material Kapton
Magnetic Gap Depth 6.0 mm
Frame Material Stamped Steel



THIELE-SMALL PARAMETERS

Equivalent Volume Vas 0.65 l
Excursion (mathematical)*** Xmax 3.50 mm
Free Air Resonance Fs 356.9 Hz
Mechanical Factor Qms 12.40
Electrical Factor Qes 2.05
Total Factor Qts 1.76
Cone Area Sd 149 cm²
Mechanical Mass Mms 9.51 g
Bl Factor Bl 8.15 Tm
Dc Resistance Re 6.4 Ohm
Inductance Le 0.21 mH at 1 kHz
Mechanical Mass Without Air Mmd 18.48 g
Mechanical Compliance Cms 0.021 mm/N



EXTRA INFO

Overall Diameter 6.57” ( 167mm)
Front Mount Baffle Cutout 5.79″ (147 mm)
Mounting Depth 2.97” (75.5 mm)
Overall Depth 3.27” (83.2 mm)
Net Weight 5.80 Lbs (2.60 kg)
Shipping Weight 6.20 Lbs (2.80 kg)
Carton Dimensions W x L x H 7.16″ x 7.16″ x 3.39” (182 x 182 x 86 mm)
