Corzus MD3000 3K W 1 Channel 4 Ohm

The Corzus MD3000 is a high efficiency 3000 Watt RMS Digital Class D full power 1 channel amplifier with low noise controlled by DSP (digital signal processor). It has extreme audio quality and Full Range (Sine) frequency response from 20Hz to 8Khz, fullrange active crossover and low-pass with selectable frequency in 4 options. Subsonic filter, RCA inputs and various protections managed by DSP and Display Indicator.

Technical information:

TOTAL RMS POWER 3000 WATTS

RMS POWER 2 OHMS 3000 WATTS

RMS POWER 4 OHMS 1500 WATTS

SENOID FREQUENCY RESPONSE (THD 0.01%) FROM 20Hz to 8KHz (-3dB)

CROSSSOVER FULL RANGE CUTTING FREQUENCY SELECTED BETWEEN FULL RANGE, 80Hz, 150Hz AND 200KHz

SELECTABLE LOW-PASS CROSSOVER CUTTING FREQUENCY BETWEEN 63Hz, 80Hz, 150Hz AND 200Hz

MINIMUM OUTPUT IMPEDANCE 2 OHMS

MAXIMUM OUTPUT DISTORTION (THD) 0.01%

TEMPERATURE PROTECTION 80 ° C

MAXIMUM CONSUMPTION 300 A

DIGITAL DISPLAY INCORPORATED TO EQUIPMENT * YES

OPERATING VOLTAGE (INPUT VOLTAGE) 10.0Vdc to 15.0Vdc

PROTECTIVE VOLTAGE (LIMIT INPUT VOLTAGE) 8.0Vdc to 16.0Vdc

RCA INPUT SENSITIVITY (AUDIO SIGNAL REQUIRED FOR MAXIMUM POWER) 0.5Vrms To 5Vrms

WEIGHT 4.4 kg.

Height: 59.1mm

Width: 270.0mm

Length: 266.0mm"
